Inclinometers

Precise and reliable – even under extreme operating conditions

The optimal solution for every application: Whether for static or dynamic measurement tasks, Kübler offers the right sensor technology for 1-axis and 2-axis inclination measurements as well as for rotation rate and acceleration measurements on all three axes. Compared to alternative measuring systems, inclination sensors offer more flexibility and degrees of freedom in system design, as they do not require a mechanical connection – for example, to a shaft or axis of rotation. This simplifies installation and significantly reduces potential sources of error. A wide range of analog and digital interfaces – optionally configurable via IO-Link – enables easy integration into modern IIoT systems.

Precise and reliable measurement

  • Suitable for the harshest environments
  • For static and dynamic applications
  • 1-axis and 2-axis versions
  • Simple commissioning and diagnostics
  • Wide range of interfaces
  • IO-Link as a door opener for IIoT

Inclinometers

Precise and reliable – even under extreme operating conditions

The optimal solution for every application: Whether for static or dynamic measurement tasks, Kübler offers the right sensor technology for 1-axis and 2-axis inclination measurements as well as for rotation rate and acceleration measurements on all three axes. Compared to alternative measuring systems, inclination sensors offer more flexibility and degrees of freedom in system design, as they do not require a mechanical connection – for example, to a shaft or axis of rotation. This simplifies installation and significantly reduces potential sources of error. A wide range of analog and digital interfaces – optionally configurable via IO-Link – enables easy integration into modern IIoT systems.
Inclinometers for static applications

Inclinometers for static applications

Precise 1- or 2-axis inclination measurement

Applications in which the overall application does not move. The measurement is based on an acceleration measuring cell that provides a precise measurement at a moderate speed. Application examples: In mobile automation such as mobile cranes, lifting tables in intralogistics through to tracked photovoltaic systems in solar industry applications, and many more.

Maximum compactness and cost efficiency
Maximum compactness and cost efficiency
  • Ideal for the tightest installation spaces
  • Can be configured for specific applications
  • Easy to adapt with Easy-Teach adapter
  • Stackable for redundant measurements
  • High degree of protection IP68/IP69k
To the IN41
Individually parameterizable
Individually parameterizable
  • Various analog interfaces adjustable
  • Adjustable measuring range
  • Filter functions depending on the application
  • Easy-Teach via teach adapter
  • IO-Link interface for parameterization (FDT/IODD)
To the IN61
Robust and precise
Robust and precise
  • Various analog interfaces
  • Optionally with additional switching outputs
  • Robust metal housing
  • Stackable for redundant measurement
  • High protection class IP69k
To the IN81
2 switching outputs
2 switching outputs
  • Individual parameterization
  • Simple commissioning
  • Spirit level function
  • IO-Link interface for parameterization (FDT/IODD)
To the IN62
Door opener for Industry 4.0 / IIoT
Door opener for Industry 4.0 / IIoT
  • Simple commissioning and diagnostics
  • Adjustable measuring range
  • Filter functions depending on the application
  • Parameterization via FDT/IODD
To the IN68
Maximum compactness and cost efficiency
Maximum compactness and cost efficiency
  • Ideal for the tightest installation spaces
  • Individual settings via the fieldbus interface
  • Stackable for redundant measurements
  • High degree of protection IP68/IP69k
To the IN48
Various fieldbus interfaces
Various fieldbus interfaces
  • Parametric filter adjustment
  • Robust metal housing
  • Stackable for redundant measurement
  • High protection class IP69k
To the IN88
For fieldbus communication
For fieldbus communication
  • Fast commissioning and diagnostics
  • LED water carriage function for visual orientation
  • Adjustable measuring ranges and filter functions
  • Wide voltage range 8...36 VDC
  • 2x M12 plug for bus IN/OUT
To the IN68
Inclinometers for dynamic applications

Inclinometers for dynamic applications

Precise 1- or 2-axis inclination measurement

Applications in which the entire application is in motion or exposed to strong vibrations and oscillations. In addition to the measurement via an acceleration measuring cell, a rotation is also determined via a rotation rate measuring cell. An intelligent calculation of the values from this sensor fusion enables the measurement result to be provided at a high speed. Application examples: In mobile automation such as wheel loaders, timber harvesters as well as forklift trucks, pallet trucks and automated guided vehicles (AGV) in intralogistics, etc.

Maximum compactness and cost optimized
Maximum compactness and cost optimized
  • Precise inclination measurement, even with movement, vibrations and oscillations
  • Ideal for the tightest installation spaces
  • Measuring range and filter individually configurable
  • Individually adaptable with Easy-Teach adapter
  • IP68/IP69k
To the IN51
For fieldbus communication
For fieldbus communication
  • Precise inclination measurement, even with movement, vibrations and oscillations
  • Individual settings via the fieldbus interface
  • Ideal for the tightest installation spaces
  • Measuring range and filter individually configurable
  • IP68/IP69k
To the IN58
Individually parameterizable
Individually parameterizable
  • Various analog interfaces adjustable
  • Adjustable measuring range
  • Filter functions depending on the application
  • Easy-Teach via teach adapter
  • IO-Link interface for parameterization (FDT/IODD)
To the IN71
2 switching outputs
2 switching outputs
  • Individual parameterization
  • Simple commissioning
  • Spirit level function
  • IO-Link interface for parameterization (FDT/IODD)
To the IN72
Door opener for Industry 4.0 / IIoT
Door opener for Industry 4.0 / IIoT
  • Simple commissioning and diagnostics
  • Adjustable measuring range
  • Filter functions depending on the application
  • Parameterization via FDT/IODD
To the IN78
For fieldbus communication
For fieldbus communication
  • Fast commissioning and diagnostics
  • LED water carriage function for visual orientation
  • Adjustable measuring ranges and filter functions
  • Wide voltage range 8...36 VDC
  • 2x M12 plug for bus IN/OUT
To the IN78

Tilt sensors for dynamic applications (6DoF)
Precise 2-axis dynamic tilt measurement

For applications requiring precise measurement of two inclination angles in all three spatial axes – even during movement, vibrations, and oscillations. The measurement is based on an inertial measurement unit (IMU) that combines three acceleration and three rotation rate sensors (6DoF) and processes their signals using intelligent sensor fusion. This allows the exact spatial orientation of an object to be determined. In addition to the calculated angle values, the six raw measurement data can also be output individually and further processed. A major advantage of the IN58.6DoF sensors is their flexible installation position, as unlike classic 1- or 2-axis inclination sensors, they do not require strictly vertical or horizontal mounting, which makes integration into machines and vehicles much easier.
For fieldbus communication
For fieldbus communication
  • Precise inclination measurement in 2 axes for dynamic applications
  • Flexible installation position Ideal for tight installation spaces
  • Measuring range and filter individually configurable
  • Easy to adapt with Easy-Teach adapter
  • High protection class IP68/IP69k
To the IN58.6DoF
