Encoders Incremental
5821
|
|
Product is discontinued
A new / comparable product is available for this product.
Large hollow shaft in standard dimension of 58 mm
Optimized proportions, optimized costs: With a total diameter of only 58 millimeters, the 5821 series has a hollow shaft with a diameter of up to 28 millimeters.
| Mechanical | |
|---|---|
| Dimension | Ø 58 mm |
| Shaft type |
16 mm hollow shaft, through 20 mm hollow shaft, through 22 mm hollow shaft, through 24 mm hollow shaft, through 25 mm hollow shaft, through 28 mm hollow shaft, through |
| Flange type |
Spring elements, short Torque brackets long |
| Working temperature | -20 °C ... +70 °C |
| Protection level |
IP64 |
| Connection types |
Radial cable M12 connector radial |
| Max. rotational speed |
2.500 min-1 |
| Weight | 400 g |
| Electrical | |
|---|---|
| Scanning | optical |
| Resolution max. |
5.000 ppr incremental |
| Power supply |
5 V DC 8...30 V DC |
| Interfaces |
Gegentakt TTL / RS422 |
| Options | |
|---|---|
| on request |
|
- Through hollow shaft from 16 mm to 28 mm.
- With cable connection or M12 plug.
- High resolution up to 5000 pulses per revolution.
| Product Certificates | ||
|---|---|---|
|
UL CoC USA/ Canada - Encoders PDF ∼ 503,1 KB | 03.2025 |
EN |
